What is the normal loss level for beam splitters 1-4
The maximum loss for typical beam splitters ranges from about 0.3 dB for low-loss PLC splitters to 20 dB for high-split or metallic-coated devices.
Typical Loss Values
- PLC and FBT Splitters
- Insertion loss depends on the splitting ratio and number of output ports.
- For a 1:2 splitter, typical insertion loss is around 3.5 dB, while a 1:4 splitter may reach 7 dB or slightly higher due to splitting and excess loss .
- Modern low-loss PLC splitters can achieve as low as 0.3 dB per output for small splits .
- Dielectric or Thin-Film Beam Splitters
- Losses are generally lower than metallic-coated splitters.
- Dichroic coatings can make losses negligible, with total output power nearly equal to input .
- Metallic coatings typically introduce higher losses, sometimes several dB, depending on reflectivity and wavelength .
- Factors Affecting Maximum Loss
- Splitting ratio: Higher splits (e.g., 1:8, 1:16) increase insertion loss.
- Coating type: Dielectric coatings minimize loss; metallic coatings increase it.
- Wavelength and angle of incidence: Loss varies with wavelength and beam angle .
- Excess loss: The difference between total input power and sum of output powers, typically 0.1–1 dB for quality splitters .
Summary Estimates for Beam Splitters 1-4
| Splitter | Typical Maximum Loss |
|---|---|
| 1 | 3–4 dB |
| 2 | 3–4 dB |
| 3 | 6–7 dB |
| 4 | 6–7 dB |
These values assume standard 1:2 to 1:4 splitting ratios and high-quality dielectric or PLC splitters. For metallic-coated or high-split devices, losses can be significantly higher, up to 20 dB in extreme cases . In practice, always check the manufacturer's datasheet for the exact insertion and excess loss for each splitter, as these values can vary with wavelength, temperature, and optical power.
