How long should cable trays be designed with expansion joints
Cable trays should be fitted with expansion joints approximately every 128 feet for steel trays and every 65 feet for aluminum trays under a 100°F temperature differential.
Recommended Spacing
The spacing of expansion joints in cable trays depends primarily on the material of the tray and the expected temperature variation. According to NEMA Standards Publication VE 1, for a 100°F temperature differential (typical winter-to-summer range):
- Steel cable trays: expansion joints every 128 feet
- Aluminum cable trays: expansion joints every 65 feet These distances ensure that thermal expansion and contraction do not cause bending, distortion, or damage to the tray or its supports.
Installation Considerations
- Support placement: Supports should be located within 2 feet of each side of the expansion joint splice plate. The tray should not be clamped too tightly to allow free movement .
- Anchoring: The tray should be anchored at the support closest to the midpoint between expansion joints, with expansion guides at other supports to allow sliding as the tray expands or contracts .
- Gap setting: The expansion joint gap should be calculated based on the installation temperature and the expected maximum and minimum tray temperatures. For example, a tray installed at 50°F with a 100°F differential may require a 3/8 inch gap .
- Material differences: Steel expands less than aluminum, which is why aluminum trays require more frequent expansion joints .
Practical Tips
- Expansion joints should be installed at regular intervals along the tray, especially in areas with large temperature swings, such as rooftops or outdoor installations .
- Standard splice plates are not suitable for expansion; slotted holes are recommended to allow sliding motion .
- Ignoring thermal expansion can lead to tray deformation, bolt elongation, or even detachment from supports . By following these guidelines, cable tray systems can safely accommodate thermal movement, maintaining structural integrity and long-term reliability.
